Product Infomation:
Size Range: 1/4" - 2" (8 - 50mm)
Body Materials: SS316
Temperature Range: -50°F to 450°F (-46°C to 232°C)
Stem Materials: SS304
Pressure Rating: 2000 psi WOG (137 Bar)
Seat Materials: RPTFE
Shutoff Rating: Zero Leakage
Ball Materials: SS304
Body Style: Two Piece
End Connections: Threaded - NPT
Ports: Full Port
Face to Face: Manufacturer Standard
Applications: General Service, Air, Water, Oil & Gas, Fire Safe
Materials List
Body - SS 316 (CF8M)
ball - SS 304
Cap - SS 316 (CF8M)
Ball Seat - RPTFE
Thrust Washer - RPTFE
Stem Packing - PTFE
Stem - SS 304
Gland Nut - SS 304
Handle Washer - SS 304
Handle Nut - A2-70
Handle - SS 201
Handle Lock - SS 201
Handle Cover - Plastic
Shipment:
Usually our lead time is 30-60 days after you place the order. The goods will be delivered at Ningbo or Shanghai Port. If you have special requirement about shipment, you can contact us.
Payment:
Our usually payment term is 30% by T/T in advance and the balance will be collect before shipment.
Our statement:
1. After you place the order, we will communicate with you according to the quantity of the order, and then choose to complete the delivery by sea or air in a short time.
2. Our workers actively pursue high-quality production and continuous innovation of products. Our products have CE certificate, reliable quality and reasonable quotation.
3. We have a complete production inspection and after-sales process. We are an efficient foreign trade team, you can trust our service.
1. Can you manufacture different standards valves according to customer requirements?
A: Yes. We can manufacture ANSI, DIN, JIS standards for different pressure & temperature & size according to different needs. So if you have any special request, you can e-mail or call us directly.
2. How to deal with product maintenance?
A: We have CE product certification, product quality can be guaranteed. If there is any damage to the product, please contact us to send the product to us by mail. We will repair the product and send it back. Or directly after the product is repaired in the local area, we will issue an invoice to repair the product at our expense.
3. Where are your delivery ports?
A: There are two main delivery ports in our company. Ningbo Port and Shanghai Port. But if you have other special requests, please contact us as soon as possible. We will try our best to satisfy you.
