Product Infomation:
Size Range: 1/4" - 2" (8 - 50mm)
Body Materials: ASTM A105
Temperature Range: -50°F to 450°F (-46°C to 232°C)
Stem Materials: ASTM A182 F316
Pressure Rating: 2000 psi WOG (137 Bar)
Seat Materials: RPTFE
Shutoff Rating: Zero Leakage
Ball Materials: ASTM A182 F316
Body Style: Two Piece
Design Standard: MSS SP-110
End Connections: Threaded - NPT
Testing Standard: MSS-SP 72
Ports: Full Port
Face to Face: Manufacturer Standard
Applications: General Service, Air, Water, Oil & Gas, Fire Safe
Materials List
Body - A105
Ball - SS 304
Cap - A105
Cap Seat - RPTFE
Ball Seat - RPTFE
Thrust Washer - PTFE
Stem Packing - PTFE
Stem - SS 304
Gland Nut - SS 304
Handle Washer - SS 304
Handle Nut - A2-70
Handle - SS 201
Handle Cover - Plastic
Shipment
Usually our lead time is 30-60 days after you place the order. The goods will be delivered at Ningbo or Shanghai Port. If you have special requirement about shipment, you can contact us.
Payment:
Our usually payment term is 30% by T/T in advance and the balance will be collect before shipment.
We can provide 24 hours service and all the details that you want to know about our product . And also we will answer the questions you raise and help you to choose the right goods.
When you receive the goods, once you found any damage, please contact with us as soon as possible. We can provide 1 year after-sales guarantee.
Q1. Can you give me a discount?
A: As you know, we are the producer, so please believe that our price is competitive. If the quantity of your is big,we can consider to give you a discount. If you have needs, you can discuss with us.
Q2. What should we pay attention to when using valves?
A: a. The rotating position of valve handle shall be reserved.
b. It cannot be used as throttling.
c. The ball valve with driving mechanism shall be installed vertically.
Q3. How long will it take for quotation?
A: We will quote within 2 working days after receiving detail information.
Q4. Could you give the sample to me for free before ordering?
A: We usually can give out sample in 3 days, but the shipment charge usually paid by your side, the fee of it will be rebound when we have formal order.
